4G LTE & 5G IOT GATEWAYS
Inseego Wavemaker 5G industrial IoT gateway S2000
Our fastest, most versatile 5G gateway
Features & specifications
Features:
The only 5G gateway that supports simultaneous 4x4 MIMO LTE + 5G
Purpose-built design with flexible antenna and mounting options
Enterprise-grade device security, third-party penetration testing, content filtering, and more
Easy-to-use Inseego Mobile™ app to optimize placement, simplify installation process, and manage device settings
Cloud API support through Inseego Connect Advanced and Inseego 5G SD EDGE
Chipset:
Qualcomm® Snapdragon™ SDX55
SIM type:
2x4FF Nano (dual SIM) w/auto-switching
Carrier certified:
Certified for the following carrier networks
Network technology:
5G Sub-6 only or Sub-6 + mmW with 4G LTE (Cat 22) fallback
SA & NSA
Dynamic Spectrum Sharing (DSS)
Data speeds:
4.2 Gbps Download /1.3 Gbps Upload*
Ports:
1x 5 Gb Ethernet RJ45 with Power over Ethernet
1x USB 3.1 Type C (USB Tethering, USB WAN Modem) 2.7 Gbps max throughput
6x Female SMA for Cellular
1x Female SMA for GNSS
1x 4 Pin Power and 1/O
Dimensions & weight:
Height:
7.8 inches (200 mm)
Width:
3.1 inches (80 mm)
Depth:
1.7 inches (45 mm)
Weight:
495 g
Operating temperature:
-30 °C to 65 °C
Security features:
Device cybersecurity agent
NAT Firewall
VPN Pass-Through, open VPN, IPsec VPN
Security hardened web interface - TLS, SSL
Fully encrypted log files
Fully encrypted cloud agent
Anti-CSRF
Session timeout
Incorrect password lockout
Web UI operating systems supported:
Windows® 10 and later
Mac OS® 10.14 and later
Linux® Ubuntu 18.04 LTS and later
Chrome OS™ c79 or later
* Theoretical max download and upload speeds. Actual speeds experienced are dependent on carrier network and coverage.
Remote device management software:
Inseego 5G SD EDGE™
Cloud-based management system provides remote monitoring & comprehensive worksite network security. It is designed to provide IT teams with real-time visibility, control, and management of critical network infrastructure. This is accomplished in a secure manner with advanced authentication, authorization, and encryption.
Inseego Connect™
The multi-tiered configuration and centralized device management platform. Inseego Connect gives enterprise IT managers and small businesses a powerful tool to seamlessly operate networks without having to be on-premises. Leverage Inseego Connect for flexible remote monitoring of device health and status.
Inseego Mobile™ app
Easily install Inseego hardware, find the best signal reception locations and troubleshoot with the easy-to-use user interface.
