5G cellular antennas

Rural internet for multi-site businesses

5G cellular antennas

Connectivity solutions that extend to any branch location, almost anywhere

Inseego's outdoor cellular antennas deliver high speeds and low latency, rivaling cable and surpassing satellite performance, even in remote areas. Additionally, all our antennas can be centrally managed using our cloud management software, Inseego Connect.

How do cellular antennas work?

Cellular antennas leverage directional aerials for aligning with the nearest tower, providing superior range and reliability over mobile phones and satellites. Setup is simple—insert a SIM card, point toward a cell tower, and you're set! For optimal performance, install them on a rooftop or building side.

Even if your phone can’t connect, our outdoor antennas can.

Mobile phones use compact omni-directional antenna with limited range. Our fixed outdoor antennas features both powerful directional and omni-directional aerials, capturing strong signal from up to 20 kilometres away when properly aligned.

Is your current internet connection meeting your business needs?

Higher upload and download speeds compared with satellite

5G cellular typically outperforms satellite with download speeds averaging 200 Mbps and uploads at 40 Mbps, compared to satellite's 100 Mbps and 12 Mbps across the US.*

I don’t know what the magic inside the Inseego RF engine is, but the Inseego products deliver higher speeds and better throughput on just one bar of connectivity than any competing solution we’ve seen.

Jason Eyre - Technology Coordinator for Murray City School District

Satellite vs Cellular cost comparison

Cellular

5G Cellular business internet costs between $50 and $100 per month for unlimited data, with average download speeds of 200 Mbps. **

Satellite

Satellite business plans range from $75 up to $1,500 per month based on data and speed allowances. You are typically also required to purchase the hardware which is tied to that particular service provider. **

Now that I’ve found the Inseego 5G FW2000, I’m deploying it at every opportunity that arises.

Dominic Eachus - President, Definitive Computer Solutions

Cellular can also be the perfect failover solution in rural environments

Cellular is quick to setup, easy to integrate with existing networks, cost effective to maintain and most importantly, reliable.

Choose your own carrier. Heck, choose two.

You’re never locked into a carrier with Inseego devices. Simply choose the carrier you want, even choose a second for added redundancy.

Although it was a high-density urban environment, this beer festival in Denver was our first time using a 5G solution at this level, and it all went very smoothly.

FestiFi - Steve Reill

Secure & compliant connectivity solutions

Ensure top-tier security & compliance with Inseego's 5G cellular routers and cloud management software. Inseego solutions meet FIPS-140-2 standards, support FedRAMP cloud hosting, and include VPN/ZTNA frameworks with SASE technology.

TAA compliant. Designed and developed in the USA.

The Inseego 5G portfolio is designed and developed in the USA and manufactured in TAA certified countries.

FCC approved connectivity for your business

Our outdoor cellular antennas are FCC-approved, ensuring robust and compliant connectivity without the risk of interference. They are the perfect choice for businesses seeking reliable performance without disrupting nearby signals and staying in compliance regulations.

Tony made the right decision when he chose 5G and Inseego. I don’t give it a second thought anymore. I know the connectivity will be there when it’s needed, every time.

Stephanie Tang - Owner of Active Physiotherapy

Easy install & support

Self-installation

While we recommend and offer professional installtion our cellular antennas be be self installed, needing just one ethernet cable because of Power over Ethernet (PoE), reducing complexity and setup time.

Product support

Our dedicated support team is available to assist with the installation of your outdoor cellular antenna (router) and to answer any other questions you may have.

Product documentation

We offer comprehensive product documentation to guide you through every step of installation and troubleshooting.

Create your own private cellular network with CBRS

CBRS empowers businesses to create secure, private networks with ease. Our FW2000 and FW2010 outdoor antennas fully support CBRS, simplifying network deployment within your facilities.

Built to scale. Manage multiple locations via the cloud.

Cloud-based management gives you a commanding view of all on premises networks, trends in real-time, and the ability to manage users and devices remotely without the need for central corporate data centers.

Inseego FW2000 features & specifications

Features:

High-gain directional antennas extend carrier wireless network coverage

Enterprise-grade device security, third-party penetration testing, content filtering, and more

Easy-to-use Inseego Mobile app to optimize placement, simplify installation process, and manage device settings

Designed to withstand extreme temperatures and IP67 rated for water and dust ingress protection

Cloud API support through Inseego Connect Advanced and Inseego 5G SD EDGE

Chipset:

Qualcomm® Snapdragon™ SDX55

Sim type:

FW2000 - Single SIM (4FF Nano)

FW2000e - Dual SIM (4FF Nano)

Certified carriers:

Certified for the following carrier networks

Verizon
T Mobile
US Cellular
AT&T

Network technology:

5G Sub-6 GHz and 4G LTE Cat 22

4x4 MIMO Sub-6, 4X4 MIMO LTE

Data speeds:

4.14 Gbps Download / 660 Mbps Upload ***

Ports:

5Gbps Ethernet LAN Port

Dimensions and weight:

Height: 16.9 inches (430 mm)

Width: 15.75 inches (400 mm)

Depth: 2.8 inches (71.1 mm)

Weight:
9.3 lbs (4.22 kg)

Operating temperature:

-22 °F to 158 °F (-30 °C to 70 °C)

Security features:

Third-party penetration testing verified

Security hardened web interface - TLS, SSL

Password hash

Anti-CSRFSession timeout

Incorrect password lockout

Firewall with adjustable settings and rules

Port filtering

Port forwarding

MAC filtering

Web UI operating systems supported:

Windows® 10 and later

Mac OS® 10.14 and later

Linux® Ubuntu 18.04 LTS and later

Remote device management software:

Inseego 5G SD EDGE™

Cloud-based management system provides remote monitoring & comprehensive worksite network security. It is designed to provide IT teams with real-time visibility, control, and management of critical network infrastructure. This is accomplished in a secure manner with advanced authentication, authorization, and encryption.

Inseego Connect™

The multi-tiered configuration and centralized device management platform. Inseego Connect gives enterprise IT managers and small businesses a powerful tool to seamlessly operate networks without having to be on-premises. Leverage Inseego Connect™ for flexible remote monitoring of device health and status.

Inseego Mobile™ app

Easily install Inseego hardware, find the best signal reception locations and troubleshoot with the easy-to-use user interface.

* www.ookla.com/articles/5g-global-reach-2024, www.cnet.com/home/internet/best-satellite-internet/

** www.cnet.com/home/internet/best-satellite-internet/, www.cnet.com/home/internet/what-is-5g-home-internet/

*** Theoretical max download and upload speeds. Actual speeds experienced are dependent on carrier network and coverage.
